50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module
  • 50W 1170-1280MHz RF Module50W 1170-1280MHz RF Module

50W 1170-1280MHz RF Module

FZX's 50W 1170-1280MHz RF Module is a sophisticated anti-drone solution, specifically designed to target and disrupt the GPS and WiFi frequencies that drones rely on for navigation and communication. This advanced module is a cornerstone of our comprehensive drone defense systems, ensuring secure airspace by effectively neutralizing drone threats.

Send Inquiry

Product Description

In the era of rampant drone misuse and the unauthorized operation of drones, airspace security faces unprecedented challenges. The 50W 1170-1280MHz Drone UAV GPS Jammer Module emerges as a vital tool in combating these risks by disrupting the GPS and WiFi frequencies integral to drone operations. This module serves as a linchpin in maintaining regulatory control and security against unauthorized drone flights. Prized for its stability and customer satisfaction, the module showcases its efficacy in addressing drone-related risks. Furthermore, our commitment to providing technical guidance and robust after-sales service ensures a seamless implementation of the drone jammer for enhanced airspace protection.

50W 1170-1280MHz RF Module Parameter

Project Index Unit Remark
Frequency Range 1170-1280 MHz Customers can customize the frequency
Operating Voltage 28 V 28-32V
Maximum output power 47±0.5 dBm 50W@≤3.5A
Gain 42±1 dB Peak-to-peak
In-band fluctuations ≤2 dB Peak-to-peak
Spurious emissions Within work zone ≤-15dBm/1MHz dBm Center frequency plus CW signal to maximum
Output power time measurement
Outside work zone 9KHz~1GHz No higher than normal noise floor clutter dBm
1G~12.75GHz dBm
Output voltage standing wave ratio ≤1.30 Without power, standard network output -10dBm
≤1.30 Power Up, Dual Directional Coupler Test
High and low temperature test Working temperature -10~+55 Low temperature can start
Gain stability ±1.5 @-40℃~+55℃ dB
Power stability ±1 @-40℃~+55℃ dB
Power supply requirements ≥4A@+28Vdc; Continuous wave output 50W
Power supply interface Power cord red positive black negative red positive black negative
RF output connector SMA SMA external screw female seat
Electric current ≤3.5 A
Size 60*150*21.5 mm
Weight 0.16 Kg

50W 1170-1280MHz RF Module Feature And Application

The primary function of a drone countermeasure RF module (Radio Frequency module) is to disrupt drones' communication and navigation systems by emitting specific radio frequencies, preventing their normal operation. These modules are essential components of drone countermeasure systems, fulfilling key purposes:

- **Communication Interference**: Transmitting on drone control frequencies, the RF module disrupts the communication link between the drone and its operator, potentially leading to control loss and activation of safety protocols.

- **Navigation Disruption**: Emitting interference signals that affect GPS reception, the RF module disrupts the drone's navigation system, resulting in inaccuracies in positioning and flight capabilities.

- **Forced Landing or Return**: Through interference with communication and navigation, the RF module can compel the drone to perform safety procedures, such as immediate landing or return to the launch site.

- **Prevention of Unauthorized Activities**: Acting as a deterrent in sensitive areas or events, the RF module inhibits unauthorized drone operations, enhancing privacy and security.

- **Protection of Critical Infrastructure**: Deployment of RF modules around military bases, government facilities, airports, and critical infrastructure safeguards against unauthorized drone intrusions, reducing security risks.

- **Ensuring Airspace Safety**: During public events or emergencies, the RF module maintains airspace safety by preventing drone interference with aviation operations or rescue missions.

In summary, the drone countermeasure RF module disrupts drone operations through targeted radio frequencies, enforcing safety measures, and safeguarding designated areas from potential drone-related threats.
